Ideal Starting Point & Trajectory for C2 Pedicle Screw Placement: a 3D Computed Tomography Analysis Using Perioperative Measurement

By Dr. Kingsley Chin


Scientific Paper

Chin KR1, Mills MV2, Seale J3, Cumming V4.

Interested medical professionals can read through the full paper, as published in The Spine Journal, here.

Background

C2 pedicle screws provide stable fixation for posterior cervical fusion. Placing C2 pedicle screws is fraught with risks, and a misplaced screw can result in cortical breach of the pedicle, resulting in injury to the vertebral artery or spinal cord.

Purpose

We sought to identify a reproducible starting point and trajectory for C2 pedicle screw placement using three-dimensional (3D) computed tomography (CT) imaging. Our aims included identifying correct cephalad and mediolateral angles used for determining the most accurate trajectory through the C2 pedicle.

Study Design

A radiographic analysis of the anatomy of the C2 pedicle using CT.

Patient Sample

A random sample of 34 cervical spine CT scans in patients without medical or surgical pathology of the cervical spine.

Outcome Measures

Normal anatomic measurements made in the axial and sagittal planes of the CT scans. Angles and measures in millimeters were recorded.

Methods

The C2 pedicles were evaluated using CT scanning with a 3D imaging application. The ideal trajectory through each pedicle was plotted. The mediolateral and cephalad angles were measured using the midline sagittal plane and the inferior vertebral body border as references. Other measurements made were the distances through the pedicle and vertebral bodies, and the surface distances along the laminae between the isthmus and the starting point of the chosen trajectories. Other measurements involving the height of the laminae were also made. The mean values, standard deviations, and intraobserver variations are presented.

Results

CT scans from 34 patients were reviewed. The sex of the patient did not predict angle measurements (p=.2038), so combined male and female patient measures are presented. The mean mediolateral angle measured was 29.2°, and the mean cephalad angle was 23.0°. The mean distance along the lamina surface between the isthmus and the starting point was 8.1 mm. The mean distance from the superior border of the lamina to the starting point was 5.7 mm. There were no statistically significant differences between the dataset collected in duplicate by the same observer (p=.74); as such, we present one data analysis on combined data from the two datasets collected.

Conclusion

It is possible to determine an ideal trajectory through the C2 pedicle. These measurements may facilitate C2 pedicle screw fixation decreasing the risk of injury to the vertebral artery, spinal cord, or nerve roots. Delineating the individual anatomy in each case with imaging before surgery is recommended.

Copyright © 2014 Elsevier Inc. All rights reserved.
